| Parameter | Value |
|---|---|
| Operating weight | 12100 kg |
| Standard bucket capacity | 0.5 m3 |
| Total length | 7590mm |
| Rear end swing radius | 2190 mm |
| Standard track width | 500 mm |
| Track length | 2880 mm |
| The total length of the track is | 3610 mm |
| Track/tire width | 2490 mm |
| Gauge | 1990mm |
| Overall height | 2875mm |
| Overall width | 2500 mm |
| Standard arm length | 2500 mm |
| engine | SAA4D95LE-5-A |
| Rated output | 72.1{98}/2200 kW(PS)/rpm |
| Displacement | 3.26 lt |
| Relief valve setting value | 31.9 MPa |
| Gradeability | 35 deg |
| Boom digging force | 61.8 deg |
| Digging force (bucket) | 86.0 kN |
| Maximum digging depth | 5520 mm |
| Maximum ground excavation radius | 8170 mm |
| Maximum digging radius | 8290 mm |
| Maximum dumping height | 6210 mm |
| Maximum digging height | 8650 mm |
| Running speed | 2.9/5.5 km/h |
| Rotation speed | 11 min-1 |
