| Parameter | Value |
|---|---|
| Machine working weight | (kg) 12600 |
| Bucket capacity | (m³)0.53 |
| Dipper length | (mm) 2100 |
| Rotation speed | (rpm)11 |
| Walking speed | (km/h)2.7-5.5 |
| Climbing ability | (%)70/30° |
| Grounding specific pressure | (Kpa) 38 |
| Bucket digging force | (kN) 93.2 |
| Digging force of stick | (kN) 61.8 |
| Engine model Komatsu | SAA4D95LE-3 |
| Rated power | (kw/rpm)66/2200 |
| Displacement | (L)3.26 |
| Maximum flow rate of main pump | (l/min) 226 |
| Working hydraulic oil circuit | (Mpa) 32 |
| Travel hydraulic circuit | (Mpa) 35 |
| Rotary hydraulic circuit | (Mpa) 29 |
| Control hydraulic circuit | (Mpa) 30 |
| Fuel tank | (L)247 |
| Hydraulic oil tank | (L) 90 |
| Engine oil replacement amount | (L) 11 |
| Coolant | (L) 13.4 |
| Total transportation length | (mm) 7599 |
| Total transportation height | (mm) 2175 |
| Overall height of cab | (mm) 2175 |
| Counterweight ground clearance | (mm) 855 |
| Track ground length | (mm) 2880 |
| Total track length | (mm) 3610 |
| Track shoe width | (mm) 500 |
| Track gauge | (mm)1990 |
| Minimum ground clearance | (mm) 400 |
| Rear end turning radius | (mm) 211 |
| Maximum digging radius | (mm) 8290 |
| Maximum excavation radius of parking surface | (mm) 8170 |
| Maximum digging depth | (mm) 5520 |
| Maximum digging height | (mm) 8610 |
| Maximum unloading height | (mm) 6170 |
| Maximum vertical excavation depth | (mm) 4940 |
| Maximum effective excavation depth | (mm) 5315 |
