| Parameter | Value |
|---|---|
| Machine working weight | (kg) 12500 |
| Bucket capacity | (m³)0.53-0.64 |
| Boom length | (mm) 4600 |
| Dipper length | (mm) 2500 |
| otation speed | (rpm) 9.5 |
| Walking speed | (km/h)5.5/2.9 |
| Climbing ability | (%) 70 |
| Grounding specific pressure | (Kpa) 40 |
| Bucket digging force | (kN) 86 |
| Digging force of stick | (kN) 72.9 |
| Maximum traction force | (kN)122.6 |
| Engine model | Komatsu SAA4D95LE-5 |
| Rated power | (kw/rpm) 69.6/2200 |
| Displacement | (L)3.26 |
| Number of cylinders | (number) 4 |
| Bore size × stroke | (mm) 95 × 115 |
| Maximum flow rate of main pump | (l/min) 242 |
| Working hydraulic oil circuit | (Mpa) 31.9 |
| Travel hydraulic circuit | (Mpa) 34.8 |
| Rotary hydraulic circuit | (Mpa) 29.2 |
| oom cylinder - number × bore × stroke | (mm) 2-105 × 995 |
| Stick cylinder - number × bore × stroke | (mm) 1-115 × 1175 |
| Bucket cylinder - number × bore × stroke | (mm) 1-90 × 885 |
| Fuel tank | (L)247 |
| Hydraulic oil tank | (L) 90 |
| Engine oil replacement volume | (L) 13 |
| Coolant | (L) 13.9 |
| Total transportation length | (mm) 7590 |
| Total transportation width | (mm) 2490 |
| Total transportation height | (mm) 2885 |
| Boarding width | (mm) 2500 |
| Track ground length | (mm) 2880 |
| Total track length | (mm) 3610 |
| Track shoe width | (mm) 500 |
| Total track width | (mm) 2490 |
| Track gauge | (mm)1990 |
| Counterweight ground clearance | (mm) 895 |
| Minimum ground clearance | (mm) 400 |
| Minimum turning radius of front working device | (mm) 2450 |
| Rear end turning radius | (mm) 2190 |
| Maximum digging radius | (mm) 8290 |
| Maximum excavation radius of parking surface | (mm) 8170 |
| Maximum digging depth | (mm) 5520 |
| Maximum digging height | (mm) 8650 |
| Maximum unloading height | (mm) 6210 |
| Maximum vertical excavation depth | (mm) 4900 |
