| Parameter | Value |
|---|---|
| Machine working weight | (kg) 23100 |
| Bucket capacity | (m³)1 |
| Boom length | (mm) 5850 |
| Dipper length | (mm) 3045 |
| Rotation speed | (rpm) 11.7 |
| Walking speed | (km/h)3.1/4.2/5.5 |
| Climbing ability | (%)70/35° |
| Grounding specific pressure | (Kpa) 50.4 |
| Bucket digging force | (kN) 172 |
| Digging force of stick | (kN) 129 |
| Engine model | Komatsu SAA6D107E-1 |
| Rated power | (kw/rpm)110/2000 |
| Displacement | (L)6.69 |
| Working form: 6-cylinder, direct injection, turbocharged, after-cooled engine | meets 2006 EPA/Tier3 and EUIIIA standards. |
| Maximum flow rate of main pump | (l/min) 439 |
| Travel hydraulic circuit | (Mpa) 37.3 |
| Rotary hydraulic circuit | (Mpa) 28.9 |
| Control hydraulic circuit | (Mpa) 3.2 pilot oil circuit |
| Boom cylinder - number × bore × stroke | (mm) 130 × 1335 × 90 |
| Stick cylinder - number × bore × stroke | (mm) 140 × 1635 × 100 |
| ucket cylinder - number × bore × stroke | (mm) 130 × 1020 × 90 |
| Fuel tank | (L) 400 |
| Hydraulic oil tank | (L) 135 |
| Engine oil replacement amount | (L) 23.1 |
| Coolant | (L) 19.8 |
| Total transportation length | (mm) 9885 |
| Total transportation width | (mm) 5190 |
| Total transportation height | (mm) 3185 |
| Overall height of cab | (mm) 3055 |
| Track ground length | (mm) 3460 |
| Total track length | (mm) 4260 |
| Track shoe width | (mm) 600 |
| Total track width | (mm) 2980 |
| Track gauge | (mm) 2380 |
| Minimum ground clearance | (mm) 440 |
| Counterweight ground clearance | (mm) 1100 |
| Rear end turning radius | (mm) 2905 |
| Maximum excavation radius | (mm) 10180 |
| Maximum excavation radius of parking surface | (mm) 10020 |
| Maximum digging depth | (mm) 6920 |
| Maximum excavation height | (mm) 10000 |
| Maximum unloading height | (mm) 7035 |
| Maximum vertical excavation depth | (mm) 6010 |
| Maximum effective excavation depth | (mm) 6700 |
| Dozer blade lift or push depth | (mm) without dozer blade |
