| Parameter | Value |
|---|---|
| Machine working weight | 25.25 tons |
| Bucket capacity: | 1.2 cubic meters |
| Boom length: | 5850mm |
| Stick length: | 3045mm |
| Overall size: | 9.885×3.18×3.185m |
| Track shoe width: | 600mm |
| Track gauge: | 2580mm |
| Minimum ground clearance: | 440mm |
| Counterweight ground clearance: | 1100mm |
| Back end turning radius: | 2940mm |
| Engine parameters | Komatsu SAA6D107E-1 |
| Maximum output power: | 123kW |
| Maximum flow rate of main pump: | 439L/min |
| Working hydraulic oil circuit: | 37.3 |
| Travel hydraulic circuit: | 37.3Mpa |
| Rotary hydraulic circuit: | 28.9Mpa |
| Fuel tank capacity: | 400L |
| Hydraulic tank: | 135L |
| Engine oil replacement amount: | 23.1L |
| Coolant: | 19.9L |
| Walking speed: | 5.5/4.2/3.1km/h |
| Bucket digging force: | 172kN |
| Digging force of stick: | 129kN |
| Largest traction: | 202kN |
| Maximum digging radius: | 10180mm |
| Maximum digging depth: | 6920mm |
| Maximum digging height: | 10000mm |
| Maximum unloading height: | 7035mm |
| Maximum vertical excavation depth: | 6010mm |
