| Parameter | Value |
|---|---|
| Machine working weight | (kg) 33000 |
| Bucket capacity | (m³)1.6 |
| Boom length | (mm) 6470 |
| Dipper length | (mm) 3185 |
| Rotation speed | (rpm) 9.5 |
| Walking speed | (km/h)3.2/4.5/5.5 |
| Climbing ability | (%)70/35° |
| Grounding specific pressure | (Kpa) 67.7 |
| Bucket digging force | (kN) 227 |
| Digging force of stick | (kN) 171 |
| Engine model | Komatsu SAA6D114E |
| Rated power | (kw/rpm)180/1900 |
| Displacement | (L)8.27 |
| Travel hydraulic circuit | (Mpa) 37.3 |
| Rotary hydraulic circuit | (Mpa) 27.9 |
| Control hydraulic circuit | (Mpa)3.2 |
| Maximum flow rate of main pump | (l/min) 535L/min |
| Boom cylinder - number × bore × stroke | (mm) 140 × 1480 × 100 |
| Stick cylinder - number × bore × stroke | (mm) 160 × 1825 × 110 |
| Bucket cylinder - number × bore × stroke | (mm) 150 × 1285 × 110 |
| Hydraulic oil tank | (L) 188 |
| Fuel tank | (L)605 |
| Engine oil replacement volume | (L) 35 |
| Coolant | (L) 32 |
| Total transportation length | (mm) 11140 |
| Total transportation width | (mm) 3190 |
| Total transportation height | (mm) 3280 |
| Overall height of cab | (mm) 3130 |
| Track ground length | (mm) 3700 |
| Total track length | (mm) 4625 |
| Track shoe width | (mm) 600 |
| Total track width | (mm) 3190 |
| Track gauge | (mm) 2590 |
| Minimum ground clearance | (mm) 500 |
| Counterweight ground clearance | (mm) 1185 |
| Rear end turning radius | (mm) 3450 |
| Maximum excavation radius | (mm) 11100 |
| Maximum excavation radius of parking surface | (mm) 10920 |
| Maximum digging depth | (mm) 7380 |
| Maximum digging height | (mm) 10210 |
| Maximum unloading height | (mm) 7110 |
| Maximum vertical excavation depth | (mm) 6480 |
| Maximum effective excavation depth | (mm) 7180 |
| Dozer blade lift or pushing depth | (mm) None |
