| Parameter | Value |
|---|---|
| Working quality with cab | (kg) 22000 |
| Front wheel distribution mass | (kg) 11000 |
| Rear wheel distribution mass | (kg) 11000 |
| Front wheel static load | (N/cm) 516 |
| Operating weight | (kg) 20 tons or more |
| Vibration frequency | (Hz)28/33 |
| Nominal amplitude | (mm)1.86/0.93 |
| Excitation force | (kN)374/290 |
| Working width/vibrating wheel width | (mm) 2130 |
| Vibrating wheel diameter | (mm) 1600 |
| High-speed driving speed | (km/h)2.69/5.25/11.12 |
| Low speed driving speed | (km/h)2.66/5.27 |
| Theoretical gradeability during vibration | (%) 30% |
| Steering angle | ±33 |
| Swing angle | (°)±11 |
| Minimum turning outer radius | (mm) 6500 |
| Crab walking distance | (mm)＜4000 |
| engine Model | SC7H190.2G3 |
| Rated power | (kw/rpm)140/1800 |
| Length | (mm)6320 |
| Width | (mm)2390 |
| Height | (mm)3200 |
| Wheelbase | (mm) 3180 |
| Minimum ground clearance | (mm) 440 |
