| Parameter | Value |
|---|---|
| Machine working weight | (kg) 9180 |
| Bucket capacity | (m³)0.2-0.45 (0.39) |
| Rotation speed | (rpm) 11.2 |
| Walking speed | (km/h)5.0/2.9 |
| Climbing ability | (%) 70% (35°) |
| Grounding specific pressure | (Kpa) 38.6 |
| Bucket digging force | (kN) 63.6 |
| Digging force of stick | (kN) 46.8 |
| Engine model | Kubota V3800DI-T-E3B |
| Rated power | (kw/rpm)60.7/2200 |
| Maximum torque | (N.m)305.4/1600 |
| Displacement | (L)3.769 |
| Number of cylinders | (number) 4 |
| Fuel tank | (L) 160 |
| Hydraulic oil tank | (L) 120 |
| Engine oil replacement volume | (L) 12 |
| Total transportation length | (mm) 6560 |
| Total transportation width | (mm) 2260 |
| Total transportation height | (mm) 2650 |
| Boarding width | (mm) 2160 |
| Total track length | (mm) 2980 |
| Track shoe width | (mm) 450 |
| Track gauge | (mm) 1810 |
| Minimum ground clearance | (mm) 360 |
| Minimum turning radius of front working device | (mm) 1990 |
| Back end turning radius | (mm) 1885 |
| Maximum height at minimum turning radius | (mm) 5700 |
| Number of supporting sprockets | (one side) (unit) 1 |
| Number of track shoes | (one side) (unit) 41 |
| Number of supporting wheels | (one side) (piece) 5 |
| Maximum digging radius | (mm) 6660 |
| Maximum digging depth | (mm) 4330 |
| Maximum digging height | (mm) 7260 |
| Maximum unloading height | (mm) 5210 |
| Maximum vertical excavation depth | (mm) 3080 |
| Bulldozing board width × height | (mm) 420 (height) |
| Dozer blade lift or pushing depth | (mm) 330/330 |
