| Parameter | Value |
|---|---|
| Machine working weight | (kg) 8850 |
| Bucket capacity | (m³)0.39 |
| Rotation speed | (rpm) 11.2 |
| Walking speed | (km/h)5.0/2.9 |
| Climbing ability | (%)70%/35° |
| Grounding specific pressure | (Kpa) 36 |
| Bucket digging force | (kN) 63.6 |
| Digging force of stick | (kN) 46.8 |
| ngine model | Isuzu 4GJ1-TABA-01-C2 |
| Rated power | (kw/rpm)53.8/2150 |
| Maximum torque | (N.m)255/1800 |
| Displacement | (L)3.059 |
| Fuel tank | (L) 160 |
| Hydraulic oil tank | (L) 130 |
| Engine oil replacement amount | (L) 9 |
| Total transportation length | (mm) 6560 |
| Total transportation width | (mm) 2260 |
| Total transportation height | (mm) 2720 |
| Overall height of cab | (mm) 2720 |
| Boarding width | (mm) 2160 |
| Track ground length | (mm) 2340 |
| Total track length | (mm) 2980 |
| Track shoe width | (mm) 450 |
| Track gauge | (mm) 1810 |
| Minimum ground clearance | (mm) 360 |
| Rear end turning radius | (mm) 1990 |
| Maximum digging radius | (mm) 6660 |
| Maximum digging depth | (mm) 4330 |
| Maximum digging height | (mm) 7260 |
| Maximum unloading height | (mm) 5210 |
| Maximum vertical excavation depth | (mm) 3080 |
| Bulldozing board | width × height (mm) 420 (height) |
| Dozer blade lift or push | depth (mm) Lift 330/Push depth 330 |
