| Parameter | Value |
|---|---|
| Machine working weight | (kg) 42400 |
| Bucket capacity | (m³)2 |
| Rotation speed | (rpm)8.6 |
| Rotary torque | (Nm) 13250 |
| Walking speed | (km/h)5.1/3.2 (high/low) |
| Ground specific pressure | (Kpa) 78 |
| Bucket digging force | (kN) 263 / 280 |
| Digging force of stick | (kN) 209 / 221 |
| Engine model | Scania DC13 |
| Rated power | (kw/rpm)245/1800 |
| Displacement | (L)12.7 |
| Number of cylinders | (number) 6 |
| Bore × stroke | (mm) 130 × 160 |
| Maximum flow rate of main pump | (l/min) 2*335 |
| Boom cylinder - number × bore × stroke | (mm) 2-165 × 115 × 1485 |
| Stick cylinder - number × bore × stroke | (mm) 1-180 × 120 × 1820 |
| Bucket cylinder - number × bore × stroke | (mm) 1-160 × 110 × 1320 |
| Fuel tank | (L) 640 |
| Hydraulic oil tank | (L) 390 |
| Total transportation length | (mm) 11835 |
| Total transportation width | (mm) 3350 |
| Total transportation height | (mm) 3570 |
| Overall height of cab | (mm) 845 |
| Boarding width | (mm) 2990 |
| Total track length | (mm) 5200 |
| Minimum ground clearance | (mm) 540 |
| Counterweight ground clearance | (mm) 1265 |
| Rear end turning radius | (mm) 3760 |
| Maximum excavation radius | (mm) 11200 |
| Maximum excavation radius of parking surface | (mm) 10980 |
| Maximum digging depth | (mm) 7435 |
| Maximum digging height | (mm) 10625 |
| Maximum unloading height | (mm) 7535 |
| Maximum vertical excavation depth | (mm) 3980 |
