| Parameter | Value |
|---|---|
| Machine working weight | (kg) 7450 |
| Bucket capacity | (m³)0.34 |
| Walking speed | (km/h)2.6/5.1 |
| Bucket digging force | (kN) 49 |
| Digging force of stick | (kN) 39 |
| Maximum traction force | (kN) 65 |
| Engine model | Volvo D3.4A |
| Rated power | (kw/rpm)42/2100 |
| Maximum torque | (N.m) 243 |
| Total transportation length | (mm) 6165 |
| Total transportation width | (mm) 2300 |
| Total transportation height | (mm) 2655 |
| Overall height of cab | (mm) 2655 |
| Boarding width | (mm) 2280 |
| Track ground length | (mm) 2200 |
| Total track length | (mm) 2850 |
| Track shoe width | (mm) 450 |
| Total track width | (mm) 2300 |
| Track gauge | (mm)1850 |
| Minimum ground clearance | (mm) 400 |
| Counterweight ground clearance | (mm) 755 |
| Minimum turning radius of front working device | (mm) 1690 |
| Rear end turning radius | (mm) 1750 |
| Maximum digging radius | (mm) 6420 |
| Maximum excavation radius of parking surface | (mm) 6270 |
| Maximum digging depth | (mm) 4100 |
| Maximum digging height | (mm) 7130 |
| Maximum unloading height | (mm) 5150 |
| Maximum vertical excavation depth | (mm) 3530 |
| Maximum effective excavation depth | (mm) 3740 |
