| Parameter | Value |
|---|---|
| Machine working weight | (kg) 7023-7435 |
| Bucket width | (mm) 854 |
| Bucket capacity | (m³)UD 0.33 |
| Boom length | (mm) 3700 |
| Dipper length | (mm) 1665 |
| Rotation speed | (rpm) 10.8 |
| Rotary torque | (Nm)16.3 |
| Walking speed | (km/h)3.2~5.1 |
| Bucket digging force | (kN) 53.2 |
| Digging force of stick | (kN) 36.3 |
| Maximum traction force | (kN)56.9 |
| Engine model | Cat® C2.4T |
| Rated power | (kw/rpm)36.5/2400 |
| Displacement | (L)2.43 |
| Bore × stroke | (mm) 87 × 102 |
| Maximum flow rate of main pump | (l/min) 147 |
| Working hydraulic oil line | (Mpa) 28.5 |
| Travel hydraulic circuit | (Mpa) 28.5 |
| Rotary hydraulic circuit | (Mpa) 24 |
| Fuel tank | (L)165 |
| Hydraulic oil tank | (L) 51 |
| Hydraulic system | (L)94 |
| Engine oil replacement volume | (L) 10.2 |
| Coolant | (L)10 |
| Total transportation length | (mm) 6055 |
| Total transportation width | (mm) 2300 |
| Total transportation height | (mm) 2630 |
| Track ground length | (mm) 2120 |
| Total track length | (mm) 2760 |
| Track shoe width | (mm) 450 |
| Minimum ground clearance | (mm) 360 |
| Counterweight ground clearance | (mm) 760 |
| Rear end turning radius | (mm) 1750 |
| Maximum digging radius | (mm) 6300 |
| Maximum excavation radius of parking surface | (mm) 6160 |
| Maximum digging depth | (mm) 4070 |
| Maximum digging height | (mm) 7240 |
| Maximum unloading height | (mm) 5200 |
| Bulldozing board width × height | (mm) 2300*450 |
| Dozer blade lift or pushing depth | (mm) 390/350 |
