| Parameter | Value |
|---|---|
| Machine working weight | (kg) 7800 |
| Bucket capacity | (m³)0.14-0.4 (0.32) |
| Boom length | (mm) 3710 |
| Dipper length | (mm) 1650 |
| Rotation speed | (rpm) 12.5 |
| Walking speed | (km/h)4.2/3.0 |
| Grounding specific pressure | (Kpa) 34.5 |
| Bucket digging force | (kN) 61 |
| Maximum traction force | (kN)56 |
| Engine model | Yanmar 4TNV98T |
| Rated power | (kw/rpm)56.5/2200 |
| Maximum torque | (N.m)298.2/1650 |
| Displacement | (L)3.319 |
| Number of cylinders | (number) 4 |
| Bore size × stroke | (mm) 98*110 |
| Maximum flow rate of main pump | (l/min) 170 |
| ravel hydraulic circuit | (Mpa) 27.5 |
| Rotary hydraulic circuit | (Mpa) 22 |
| Control hydraulic circuit | (Mpa) 3.9 |
| Fuel tank | (L)178 |
| Hydraulic oil tank | (L) 60 |
| Hydraulic system | (L)110 |
| Total transportation length | (mm) 6130 |
| Total transportation width | (mm) 2275 |
| Total transportation height | (mm) 2625 |
| Track ground length | (mm) 2230 |
| Total track length | (mm) 2845 |
| Track shoe width | (mm) 450 |
| Total track width | (mm) 2200/2350 |
| Track gauge | (mm)1750 |
| Minimum ground clearance | (mm) 380 |
| Maximum digging radius | (mm) 6375 |
| Maximum excavation radius of parking surface | (mm) 6225 |
| Maximum digging depth | (mm) 4150 |
| Maximum digging height | (mm) 7150 |
| Maximum unloading height | (mm) 5080 |
| Maximum vertical excavation depth | (mm) 3230 |
| Dozer blade lift or push depth | (mm) 425/300 |
