| Parameter | Value |
|---|---|
| Machine working weight | (kg) 6700 |
| Bucket capacity | (m³)0.33 |
| Rotation speed | (rpm)10.7 |
| Rotary torque | (Nm)12.9 |
| Walking speed | (km/h) high 5.0/low 3.4 |
| Climbing ability | (%) 70% (35°) |
| Grounding specific pressure | (Kpa) 31 |
| Bucket digging force | (kN) 55 |
| Digging force of stick | (kN) 40 |
| Maximum traction force | (kN) 47.8 |
| Engine model | Yanmar 4TNV98-AVHBW |
| Rated power | (kw/rpm)42.4/2100 |
| Displacement | (L)3.318 |
| Number of cylinders | (number) 4 |
| Bore × stroke | (mm) 98 mm × 110 mm |
| Maximum flow rate of main pump | (l/min)2×63+1×52.5 |
| Working hydraulic oil circuit | (Mpa) 26 |
| Travel hydraulic circuit | (Mpa) 31.4 |
| Rotary hydraulic circuit | (Mpa) 22.6 |
| Pilot oil circuit | (MPa) 3.9 |
| Pilot pump flow | (L/min) 21 |
| Fuel tank | (L)135 |
| Hydraulic oil tank | (L) 60 |
| Hydraulic system | (L)100 |
| Engine oil replacement volume | (L) 12.3 |
| Coolant | (L)8 |
| Total transportation length | (mm) 6,080 |
| Total transport width | (mm) 2,260 |
| Total transportation height | (mm) 2,600 |
| Overall height of cab | (mm) 2,600 |
| Boarding width | (mm) 2,260 |
| Counterweight ground clearance | (mm) 760 |
| Total track length | (mm) 2,765 |
| Track shoe width | (mm) 450 |
| Total track width | (mm) 2,200 |
| Track gauge | (mm)1,750 |
| Minimum ground clearance | (mm) 360 |
| Minimum turning radius of front working device | (mm) 1,720 |
| Rear end turning radius | (mm) 1,750 |
| Maximum digging radius | (mm) 6320 |
| Maximum excavation radius of parking surface | (mm) 6,170 |
| Maximum digging depth | (mm) 4,170 |
| Maximum digging height | (mm) 7150 |
| Maximum unloading height | (mm) 5060 |
| Maximum vertical excavation depth | (mm) 3,730 |
| Maximum effective digging depth | (mm) 3,800 |
| Bulldozer width × height | (mm) 2,320 × 435 |
| Dozer blade lifting or pushing depth | (mm) 400×280 |
