| Parameter | Value |
|---|---|
| Machine working weight | (kg) 5705 |
| Bucket capacity | (m³)0.22 |
| Dipper length | (mm) 1500 |
| Rotation speed | (rpm) 11.3 |
| Walking speed | (km/h)3.0~5.0 |
| Grounding specific pressure | (Kpa) 31.1 |
| Maximum traction force | (kN)51 |
| Engine model | Cat C2.4 |
| Rated power | (kw/rpm)34.1/2400 |
| Displacement | (L)2.43 |
| ore size × stroke | (mm) 87*102 |
| Fuel tank | (L)105 |
| Hydraulic oil tank | (L) 53 |
| Hydraulic system | (L)104 |
| Engine oil replacement volume | (L) 9.5 |
| Coolant | (L)10.0 |
| Total transportation length | (mm) 5766 |
| Total transportation height | (mm) 2143 |
| Overall height of cab | (mm) 2540 |
| Track shoe width | (mm) 400 |
| Total track width | (mm)1980 |
| Minimum ground clearance | (mm) 306 |
| Rear end turning radius | (mm) 1585 |
| Scope of work | |
| Maximum digging radius | (mm) 5952 |
| Maximum excavation radius of parking surface | (mm) 5832 |
| Maximum digging depth | (mm) 3741 |
| Maximum digging height | (mm) 5425 |
| Maximum unloading height | (mm) 3811 |
| Maximum vertical excavation depth | (mm) 2274 |
| Bulldozing board width × height | (mm) 1980*375 |
| Dozer blade lifting or pushing depth | (mm) 420*615 |
