| Parameter | Value |
|---|---|
| Machine working weight | (kg) 21100 |
| Bucket capacity | (m³)1 |
| Boom length | (mm) 5700 |
| Stick length | (mm) 2500/2900 (HD type) |
| Rotation speed | (rpm)10.9 |
| Rotary torque | (Nm) 61.8 |
| Walking speed | (km/h)5.4 |
| Climbing ability | (%)70/35° |
| Bucket digging force | (kN) 125 |
| Digging force of stick | (kN) 104 |
| Maximum traction force | (kN) 205 |
| power system | |
| Engine model | Cat C7.1 |
| Rated power | (kw/rpm)112/1800 |
| Displacement | (L)7.01 |
| Number of cylinders | (number) 6 |
| Bore × stroke | (mm) 105 × 135 |
| Maximum flow rate of main pump | (l/min) 404 |
| Pilot pump flow | (L/min)32.4 |
| Pilot oil circuit | (MPa) 39 |
| Working hydraulic oil circuit | (Mpa) 34.3 |
| Travel hydraulic circuit | (Mpa) 35 |
| Rotary hydraulic circuit | (Mpa) 25 |
| Main overflow set pressure | (Mpa) 35 |
| Fuel tank | (L) 410 |
| Hydraulic oil tank | (L) 138 |
| Hydraulic system | (L)260 |
| Engine oil replacement amount | (L) 22 |
| Coolant | (L) 25 |
| Total transportation length | (mm) 9460 |
| Total transportation width | (mm) 2800 |
| Total transportation height | (mm) 3030 |
| Overall height of cab | (mm) 2950 |
| Boarding width | (mm) 2800 |
| Track ground length | (mm) 3270 |
| Total track length | (mm) 4080 |
| Track shoe width | (mm) 600/700/790 |
| Total track width | (mm) 2800 (600mm track shoe) |
| Track gauge | (mm) 2200 |
| Minimum ground clearance | (mm) 450 |
| Counterweight ground clearance | (mm) 1020 |
| Rear end turning radius | (mm) 2750 |
| Maximum excavation radius of parking surface | (mm) 9890 |
| Maximum digging depth | (mm) 6720 |
| Maximum digging height | (mm) 9490 |
| Maximum unloading height | (mm) 6490 |
| Maximum vertical excavation depth | (mm) 5690 |
| Maximum effective digging depth | (mm) 6380 |
