| Parameter | Value |
|---|---|
| Machine working weight | (kg) 34600 |
| Bucket capacity | (m³)1.88 |
| Boom length | (mm) 6500 |
| Dipper length | (mm) 2800 |
| Rotation speed | (rpm)8.3 |
| Rotary torque | (Nm) 109 |
| Walking speed | (km/h)4.6 |
| Climbing ability | (%) 70 |
| Maximum traction force | (kN) 300 |
| power system | |
| Engine model | Cat C9 ACERT |
| Rated power | (kw/rpm) 208 |
| Displacement | (L)8.8 |
| Bore size × stroke | (mm) 112 × 149 |
| Hydraulic system | |
| Maximum flow rate of main pump | (l/min) 281 |
| Pilot pump flow | (L/min) 40 |
| Pilot oil circuit | (MPa) 4 |
| Main overflow set pressure | (Mpa) 35 |
| oil capacity | |
| Fuel tank | (L) 620 |
| Hydraulic oil tank | (L) 175 |
| Hydraulic system | (L)410 |
| Engine oil replacement amount | (L) 41 |
| Coolant | (L) 40 |
| Body size | |
| Total transportation length | (mm) 11210 |
| Total transportation width | (mm) 3190 |
| Total transportation height | (mm) 3670 |
| Overall height of cab | (mm) 3140 |
| Total track length | (mm) 4590 |
| Track shoe width | (mm) 600 |
| Track gauge | (mm) 2590 |
| Minimum ground clearance | (mm) 510 |
| Counterweight ground clearance | (mm) 1220 |
| Rear end turning radius | (mm) 3490 |
| Scope of work | |
| Maximum excavation radius of parking surface | (mm) 11760 |
| Maximum digging depth | (mm) 8210 |
| Maximum digging height | (mm) 10730 |
| Maximum unloading height | (mm) 7510 |
| Maximum vertical excavation depth | (mm) 6290 |
